The R2350 G6 is a general rack server developed by ZTE based on the fifth-generation AMD EPYC 9005 series of high-performance processors. It uses a secure and reliable software and hardware system, and has multiple cores, high throughput, strong single-thread capability, high computing performance,processors.
High performance and high density
Supports one AMD EPYC 9005 series processor, a maximum of 192 cores, and 384 threads.Supports a maximum of four dual-width full-length GPU cards.
High Scalability
Supports diversified storage configurations. A maximum of thirty-five 2.5″ disk slots or sixteen 3.5″ disk slots + 4 2.5″ disk slots are supported.
Sixteen PCIe 5.0 expansion slots are supported to meet the flexible expansion requirements of network and storage control.
Easy management and convenient maintenance
System health can be fully monitored, and core components can be monitored and diagnosed
Green, energy-saving, and environmental protection
80PLUS high-efficiency platinum/titanium power supplies. High-efficiency fans are used to support intelligent rotation speed adjustment. Lead-free design for environmental protection. Supports cold plate liquid cooling
Technical Specifications
Form
2U rack server
Processor
Supports one AMD EPYC 9005 series processor. Each processor supports a maximum of 192 cores and supports hyper-threading.
Memory
Twelve DDR5 memory slots, maximum rate: 6400MT/s
Hard disk controller
Supports RAID 0/1/5/6/10/50/60 and power-off protection.
Local storage
Supports a maximum of thirty-five 2.5″ disk slots or sixteen 3.5″ disk slots and +4 2.5″ disk slots.
A maximum of thirty-two U.2/E1S/E.3.5 are supported
Video card
Integrated video card, optional PCIe standard video card
System Management
Web management interface, which supports IPMI2.0, SNMP, RedFish, and KVM Over IP.
PCIe slot
Supports a maximum of sixteen PCIe expansion slots (including one OCP 3.0 slot).
External Device Interface
Five USB interfaces (two rear USB3.0 interfaces, one front USB3.0 interface, one internal USB3.0 interface, and one front USB2.0 interface)
Two VGA interfaces (one on the front end and one on the back end)
One serial port (TYPE-C)
One IPMI GE management interface
Power supply
Two CRPS standard power supplies that support hot swapping and 1+1 redundancy
Optional 800W/1300W/1600W/2000W/2700W/3200W, platinum/titanium power supply
Supports 110V/220V AC, 240V/336V HVDC, and-48V DC.
Environmental Conditions
Operating temperature: 5℃ – 45℃ (The operating temperature is affected by different configurations. For details, refer to the technical document.)
Storage temperature:-40℃ – 65℃
Operating humidity: 8% – 90% RH, non-condensing
Transportation and storage humidity: 5% – 95% RH, non-condensing
Altitude: Less than or equal to 3,000m. When the altitude is higher than 900m, the operating temperature decreases by 1° C every 300m above sea level. If the altitude is above 3,000m, mechanical hard disks cannot be configure.
System Dimensions
436 mm x 87 mm x 830 mm (W x H x D), excluding flanges and guide rails
Standard 19-inch rack type (rack depth: >=1.2 m)
Microsoft Windows Sever, Red Hat Enterprise Linux, SUSE Enterprise Linux, VMware ESXi, and Ubuntu…
Note:The official website information is only for reference. For specific server sales, please contact the local representative office;
The configuration support is affected by the choice of different models.Please refer to the detailed product technical documentation for details.
R2350 G6
Opis
R2350 G6
High performance and high density
Supports one AMD EPYC 9005 series processor, a maximum of 192 cores, and 384 threads.Supports a maximum of four dual-width full-length GPU cards.
High Scalability
Supports diversified storage configurations. A maximum of thirty-five 2.5″ disk slots or sixteen 3.5″ disk slots + 4 2.5″ disk slots are supported.
Sixteen PCIe 5.0 expansion slots are supported to meet the flexible expansion requirements of network and storage control.
Easy management and convenient maintenance
System health can be fully monitored, and core components can be monitored and diagnosed
Green, energy-saving, and environmental protection
80PLUS high-efficiency platinum/titanium power supplies. High-efficiency fans are used to support intelligent rotation speed adjustment. Lead-free design for environmental protection. Supports cold plate liquid cooling
A maximum of thirty-two U.2/E1S/E.3.5 are supported
Two VGA interfaces (one on the front end and one on the back end)
One serial port (TYPE-C)
One IPMI GE management interface
Optional 800W/1300W/1600W/2000W/2700W/3200W, platinum/titanium power supply
Supports 110V/220V AC, 240V/336V HVDC, and-48V DC.
Storage temperature:-40℃ – 65℃
Operating humidity: 8% – 90% RH, non-condensing
Transportation and storage humidity: 5% – 95% RH, non-condensing
Altitude: Less than or equal to 3,000m. When the altitude is higher than 900m, the operating temperature decreases by 1° C every 300m above sea level. If the altitude is above 3,000m, mechanical hard disks cannot be configure.
Standard 19-inch rack type (rack depth: >=1.2 m)
Note:The official website information is only for reference. For specific server sales, please contact the local representative office;
The configuration support is affected by the choice of different models.Please refer to the detailed product technical documentation for details.
